Omron Automation H5CXL8DNDC1224AC24

2 sold in last 8 hours
industrynova
In stock
$217.62
Product Attribute Attribute Value Approvals IP66, UL508 Type 4X Connection Type Socket Contact Form 5 A...
$217.62

customers are viewing this product
Omron Automation H5CXL8DNDC1224AC24
Product Attribute Attribute Value
Approvals IP66, UL508 Type 4X
Connection Type Socket
Contact Form 5 A at 250VAC/30 VDC
Depth 0.079" (2mm)
Dimensions 58H x 48W x 62.5D
Display Digit Height 10, 12 mm
Display Type Digital, LCD
Enclosure Rating IP66
Function Timer
Input Type NPN
IP Rating IP66
Measuring Range 0.001 to 9.999, 0.01 to 99.99, 0.1 to 999.9, 1 m to 99 h 59 m, 1 s to 99 m 59 s, 1 to 9999 hrs., m, sec.
Mounting Type Panel
Number of Digits 4 Digits x 6 Rows
Number of Inputs 3
Number of Outputs 1
Output Type SPDT
Primary Type Digital Timer
Series H5CX Series
Special Features EEPROM
Supply Voltage 12 to 24, 24 VAC, VDC VAC, VDC
Temperature Range Maximum of +55 °C
Temperature, Opening, Maximum +55 °C
Termination Screw Terminal
Type Electronic

Overview

Features:

  • Short Body with Depth of Only 59 mm (for 24-VAC/12 to 24 VDC Models with Screw Terminals)
  • Character Height of 12 mm for Better Readability (on Models with 4 Digits)
  • The Present Value Display Characters Can Be Switched Between Red, Green, and Orange
  • Power Supply Circuit and Input Circuits Are Isolated for Safety and Reliability
  • New Set Value Limit and Output Counter Functions Have Been Added
  • Front Panel Can Be Changed to White or Light Gray
  • Models with Instantaneous Contact Output Added to the Series
